17" Panel Mount and 23" Universal Mount Monitor with DC Power shown

DC Power Versions of All Industrial Monitors and Touch Screens

Written by

In case you didn’t already know, all of Hope Industrial Systems’ industrial monitors and touch screens are available with either AC or DC power input. These units operate with an input range of 9.6 to 36.6 VDC and are equipped with an industrial pluggable terminal block with locking screws. An AC-to-DC power supply is available for bench testing. These monitors include the same 4-year warranty, 30-day total satisfaction guarantee, quick shipping, and superior customer service that you have come to expect from Hope Industrial Systems.

17" Panel Mount and 23" Universal Mount Monitor with DC Power shown
Cable exit views of 17″ Panel Mount (left) and 23″ Universal Mount (right) monitors showing DC input

Specifications

DC Power Input Terminal Block with Locking Connector
DC input terminal block and locking connector
  • Available on all Hope Industrial monitors and touch screens
  • 9.6 VDC/2.5 A to 36.6 VDC/0.65 A, 24 W max
  • Three-wire industrial pluggable locking connector (with DC positive, DC ground, Earth ground)
  • AC/DC power supply for bench testing available:
    • AC input: 100 to 240 VAC, 50-60 Hz
    • DC output: 19 VDC, 2.1 A
New Fixed Wall Mount Keyboard, shown in Stainless Steel with R3 Keypad

New Fixed Wall Mount Keyboards to Complete Your Workstation

Written by

New Fixed Wall Mount Keyboard, shown in Stainless Steel with R3 KeypadHope Industrial Systems is excited to introduce our new Industrial Fixed Wall Mount Keyboards. Designed to be bolted to any vertical surface with cables routed behind the mounting surface, this new mounting option provides the user with a clean and uncluttered installation. Starting at just $735, these new keyboard models include the same rugged industrial specifications as our existing keyboards and include our standard 4-year warranty.

Read More

KVM Extender mounted to rear of 19" Universal Mount Monitor

Place Your Industrial Operator Station up to 300 m Away from Your PC with a KVM Extender

Written by

KVM Extender mounted to rear of 19" Universal Mount Monitor
Monitor-Mounted KVM Extender attached to rear of 19″ Universal Mount Monitor

Our line of industrial KVM Extenders allows you to place your industrial monitor or touch screen (and mouse, keyboard or other devices) up to 300 m (1000′) away from the computer or server using a single shielded CATx cable. This way, the non-industrial computer can be kept safely in a controlled environment, while your industrial monitor handles the tough conditions of the factory floor.

Read More

Workstation with Industrial TC Enclosure and Dell Box PC 3000 Embedded Computer

12,960 Different Ways to Configure Your Industrial Operator Station

Written by

Workstation with Industrial TC Enclosure and Dell Box PC 3000 Embedded ComputerHope Industrial Systems’ Industrial Operator Stations are designed to provide a low-cost platform that can be configured in more than 12,960 ways. Our workstations consist of an industrial Universal Mount Monitor, cable exit plate option, and monitor mount. Other optional accessories, including PC/thin client enclosures, keyboards, and KVM extenders, are available depending on your requirements. Read More

Hope Industrial UM22 Touchscreen and Keyboard with Raspberry Pi internally integrated

Calibrating a Hope Industrial Touch Screen on a Raspberry Pi

Written by

Hope Industrial UM22 Touchscreen and Keyboard with Raspberry Pi internally integrated

Please note: Linux changes regularly. Because of this, the information below becomes outdated quickly. Please contact our support team for additional assistance.

We have many customers who use our Industrial Touch Screens and Workstations as a rugged, wash-down capable front-end for a simple Raspberry Pi computer.  Over the years we have written several articles about ways to both physically mount and install/calibrate the touch screen using the Raspbian OS.  We’ve also written some general Linux overview articles that review the various ways to use our displays with Linux.

Read More

Configuration with Stainless Steel Cover Plate, 4.0 m Conduit, and 4.6 m Power, Video and USB Cables

New Pre-Built Conduit/Cable Assemblies

Written by

Configuration with Stainless Steel Cover Plate, 4.0 m Conduit, and 4.6 m Power, Video and USB Cables
USB/Digital Video Assembly with 4.0 m Conduit and 4.6 m Power, Digital Video, and USB cables, and Stainless Steel Cover Plate

Hope Industrial Systems is happy to announce our pre-built conduit, cable, and cover plate assemblies for use with our fully enclosed Universal Mount Monitors are now available in all international markets. Because configurations are now pre-assembled, we will be lowering prices on all conduit assemblies.

Read More

Workstation with Industrial TC Enclosure and Dell Box PC 3000 Embedded Computer

Thin Client Enclosures Now Pre-Configured for the Dell Box PC 3000

Written by

Workstation with Industrial TC Enclosure and Dell Box PC 3000 Embedded Computer
Thin Client / Small PC Workstation
with Dell Box PC 3000

Hope Industrial Systems is pleased to announce that our Thin Client / Small PC Enclosure models have been updated to include pre-drilled mounting points for the Dell Box PC 3000. The compact size, efficient thermal design and high temperature rating of the Box PC 3000 make it an ideal fit for our Industrial Small Form Factor PC Enclosures. The Dell Box PC 3000 is maintained by Dell’s industry-leading customer support and service.

Read More

Full travel industrial keyboard with rubber overlay

New Full-Travel Keyboards with Touchpad

Written by

Monitor-Mounted Full-Travel Keyboard with Capacitive Touchpad

Hope Industrial Systems is excited to introduce our new Industrial Full-Travel Keyboards with Capacitive Touchpad. These new keyboards are available in our four keyboard enclosure options:

  • Monitor-Mounted – mount directly to the bottom of our Universal Mount Monitors
  • Benchtop – place on a bench or table top
  • Panel Mount – mount in a panel or other surface
  • Folding Wall Mount – attach to any vertical surface; fold out of the way when not in use

Read More

New Combined Conduit / Compression Gland Cable Exit Plate

New Combined Conduit / Compression Gland Cable Exit Plate

Written by

New Combined Conduit / Compression Gland Cable Exit Plate
New Combined Conduit / Compression Gland Cable Exit Plate

We are pleased to announce the availability of our combined Conduit/Compression Gland Cable Exit Plate. This new option provides our rugged, fully-sealed conduit option (generally used between our Universal Mount Display and an enclosure or pedestal) with the flexibility of our Compression Gland for connecting nearby peripherals like a barcode scanner or mouse.

Read More
